Series

64.2 HV Control Gate Valve

  • 64240-PEAG
View dimensions

Series

64.2 HV Control Gate Valve

Article number
64240-PEAG
DN 100 - 400

For High Cycle Vacuum Control and Isolation

  • Technical data
  • Downloads
Size
DN 100 (4")
Flange
ISO-F
Material
Stainless steel
Actuator
Stepper motor
Position Indication Signal
No
Solenoid
No
Controller
with Sensor Power Supply
Interface
RS232, 1 Sensor
Pressure Min.
1 × 10-8 mbar
Pressure Max.
2.0 bar (abs)
Conductance
1700 ls⁻¹
Differential Pressure on Plate
≤ 2 bar
Differential Pressure at opening
≤ 0.03 bar
Open to close
6 s
Close to open
6 s
Pressure control (throttling) default speed
3 s
Max. temperature valve body
≤ 150 °C
Max. Temperature Actuator
≤ 50 °C
Weight
17 kg / 37.48 lbs
Controller Configuration
SPS
Controller interface + sensors
RS232 interface / 1 sensors
Add-Ons for Your Product
Valve
Gate
Actuator
Temperature Management

64.2 HV Control Gate Valve 64240-PEAG Manual

PDF 2 MB Download

64.2 HV Control Gate Valve 64240-PEAG 2D Dimension Drawing

PDF 653 KB Download
